Key Selling Points
- Ultra-Compact Design: Miniature size (Φ23mm×46mm) for space-constrained applications.
- High Accuracy: ±1m + 0.25%L precision ensures reliable data.
- Rugged Performance: Operates in -20°C to +50°C environments.
- Low Power: 0.3W max consumption for extended use.
- Easy Integration: TTL interface and plug-and-play commands (single/1Hz modes).
Applications
- Ideal for UAV navigation
- robotic obstacle avoidance
- smart traffic systems
- construction surveys
- security monitoring
- outdoor adventures
Specifications
| Parameter | Specification |
|---|---|
| Wavelength | 905nm±10nm@25℃ |
| Safety Standard | Complies with IEC60825-1 Class 1 |
| Maximum Range | ≥1000m (for large ground targets, reflectivity: 0.3, relative humidity ≤60%, visibility ≥10Km) |
| Blind Zone | ≤10m |
| Accuracy | ≤±1m (≤300m); ≤±2m (>300m) |
| Accuracy Rate | ≥98% |
| Frequency | Single-shot, 1Hz |
| Power Supply Voltage | 3.3V |
| Standby Power Consumption | ≤0.6W |
| Average Power Consumption | ≤0.8W |
| Startup Peak Current | ≤1A@560us |
| Ranging Peak Current | ≤400mA@170us |
| Ranging Response Time | ≤100ms |
| Communication Interface | TTL (3.3V) |
| Baud Rate | 115200bps |
| Operating Temperature | -20℃～55℃ |
| Environmental Protection Requirement | Complies with ROHS 2.0 |
| Shock Resistance | 750g, 1ms, 5000 times |
| Air Tightness | IP67 |
| Overall Dimension | ≤47mm×Φ24mm |
| Weight | ≤20g |
| Safety Design | Complies with GJB 900A-2012 |
Note: All performance specifications and interfaces can be customized to meet specific requirements.
