Key Selling Points
- Ultra-Compact & Lightweight (≤100g, 68×42.5x55mm)
- Extreme Environment Resilience (-40°C ~ +60°C)
- Adjustable Repetition Rate (1Hz–10Hz)
- High Accuracy Rate (≥98%) with Low Beam Divergence (≤0.3mrad)
Applications
- Military targeting
- Hunting
- Surveying
- Industrial inspection
- Integration with electro-optical systems
Technical Specifications
| Parameter | Specification |
|---|---|
| Laser Wavelength | 1535±5nm |
| Maximum Range | ≥ 8 km (Conditions: Atmospheric visibility ≥ 10 km, relative humidity ≤ 80%, moderate atmospheric turbulence, target reflectance coefficient of 0.2; Target size: 2.3 m × 2.3 m) |
| Minimum Range | ≤30m |
| Ranging Accuracy | ≤±1m |
| Frequency | 1Hz ~ 10Hz (adjustable) |
| Continuous Ranging Time | ≥30min |
| Accuracy Rate | ≥98% |
| Beam angle | ≤0.3mrad |
| Communication Interface | RS422 |
| Baud Rate | 115200 |
| Dimensions | ≤(L)68mm × (W)42.5mm × (H)50 mm |
| Weight | ≤100g |
| Supply Voltage | 9~15V |
| Operating Temperature | -40℃~+60℃ |
| Storage Temperature | -50 ℃ ~ +70 ℃ |
| Main Functions | a) Single-shot and continuous laser ranging functions; b) Laser pulse cumulative counting; c) Self-test (power-on self-test, startup self-test, and periodic self-test). |
| Shock | Powered-on unit tested per GJB-150.18A-2009, Procedure I. Shock applied along three mutually perpendicular axes (one parallel to objective optical axis) with terminal sawtooth waveform: 40g peak acceleration, 11ms duration, 3 shocks per direction (±) on each axis. |
| Vibration | Prototype in storage case per GJB-150.16A-2009, Fig C.3 & Table C.7. Vibration applied along three mutually perpendicular axes (one parallel to objective optical axis), 40 min per axis. |
Note: All performance specifications and interfaces can be customized to meet specific requirements.
