Key Selling Points
- Ultra-Compact Design: Weighs only 75g (2.6oz) and fits in tight spaces (51x35x45mm)
- Military-Grade Durability: Operates flawlessly in extreme temperatures and humidity (tested to MIL-STD-810G)
- Adaptive Performance: Adjustable repetition rate (1-10Hz) for dynamic scenarios
- Pinpoint Accuracy: 98% success rate with ≤0.5mrad beam divergence
Applications
- Surveying
- Forestry management
- Drone navigation
- Industrial robotics
- Security surveillance
Technical Specifications
| Parameter | Specificationr |
|---|---|
| Wavelength | 1535 nm ± 5 nm |
| Maximum Range | ≥ 6 km (Conditions: Atmospheric visibility ≥ 12 km, Relative humidity ≤ 80%; Target: 2.3m × 2.3m, Reflectivity ≥ 0.2) |
| Minimum Range | ≤ 30 m |
| Accuracy | ≤ ± 1 m |
| Beam Angle | ≤ 0.5 mrad |
| Accuracy Rate | ≥ 98% |
| Frequency | 1 Hz - 10 Hz adjustable |
| Communication Interface | RS422 |
| Baud Rate | 115200 |
| Continuous Ranging Duration | ≥ 30 min |
| Power Supply Voltage | +9 V ~ +15 V DC |
| Power Consumption | Peak: ≤ 8 W; Quiescent (Power-on, laser off): ≤ 1.5 W; Active (Continuous ranging @ 10Hz): ≤ 3.5 W |
| Operating Temperature | -40 ℃ ~ +60 ℃ |
| Storage Temperature | -50 ℃ ~ +70 ℃ |
| Dimensions | ≤51mm×35mm×45mm |
| Weight | ≤75g |
Note: All performance specifications and interfaces can be customized to meet specific requirements.
