Core Technology & Key Selling Points
- Military-Grade Eye Safety:
Class 1 laser safety certification (1535nm wavelength) – highest safety standardfor human operations.
- Extreme Environment Resilience:
Operates at -40°C to +60°C with aircraft-grade shock resistance (>75g@6ms). Perfect for drones, robotics, and field equipment.
- Multi-Target Precision:
Detects up to 3 targets simultaneously with ±1m accuracy – ideal for complex terrains.
- Ultra-Compact Design:
≤40g weight and 50×23×33.5mm size – integrates seamlessly into handheld/vehicle systems.
- Smart Power Management:
Low 0.2W standby power & ≤3W peak – extends battery life in portable devices.
Technical Specifications Table
| Parameter | Specification |
|---|---|
| Eye Safety Class | Class 1 |
| Laser Wavelength | 1535±5nm |
| Receiver Aperture | Φ16mm |
| Maximum Range | ≥6km (Large target: building) |
| ≥5km(Vehicle: 2.3m×2.3m) | |
| ≥3km (Human: 1.7m×0.5m) | |
| Blind Zone | ≤15m |
| Accuracy | ≤±1m |
| Frequency | 1～10Hz |
| Distance Resolution | ≤30m |
| Accuracy Rate | ≥98% |
| False Alarm Rate | ≤1% |
| Communication Interface | TTL serial port (RS422 customizable) |
| Baud Rate | 115200(default) |
| Voltage | DC 5～28V |
| Average Power Consumption | ≤1W@5V (1Hz operation) |
| Peak Power Consumption | ≤3W@5V |
| Standby PowerConsumption | ≤0.2W |
| Dimensions | ≤50mm×23mm×33.5mm |
| Weight | ≤40g |
| Operating Temperature | -40℃～+60℃ |
| Storage Temperature | -55℃～+70℃ |
| Shock Resistance | >75g@6ms |
| Vibration Resistance | Propeller aircraft vibration environment |
Notes:
Measurement conditions: Target reflectivity ≥20%, atmospheric visibility >20km, no rain/fog interference.
All tolerances (e.g., ±5nm wavelength, ±1m accuracy) comply with MIL-STD-810H environmental testing standards.
Interface customization (Item 13) requires firmware configuration; physical port remains unchanged .
Critical Applications
- Defense & Security: Border surveillance, target acquisition
- Industrial Automation: Robotic navigation, collision avoidance
- Surveying & Mapping: Drone-based terrain scanning
- Search & Rescue: Long-range detection in low-visibility conditions
Functional Highlights
- Adaptive Targeting:Auto-selects first/last targetor distance-gatedobjects.
- Self-Diagnostics:On-board health checks at startup.
- Rapid Deployment:TTL/RS422 protocols + SDK for quick integration.
