Key Selling Points
- Ultra-lightweight (≤60g) & miniaturized design (48.5x36x26mm)
- High accuracy (±1m) with 98%+ reliability
- Rugged performance (-40°C to +60°C)
- Adjustable repetition rate (1Hz–10Hz)
- Low power consumption (5V DC)
Applications
- Tactical targeting
- Drone navigation
- Surveying
- Hunting
- Environmental monitoring
- Industrial automation
Specifications
| Parameters | Index |
|---|---|
| Laser wavelength | 1535±5nm |
| Maximum measuring range | ≥3000m (visibility ≥ 10 km; Relative humidity ≤ 80% with moderate atmospheric turbulence and a target reflectivity of 0.2, for a 2.3 m × 2.3 m target) |
| Minimum measuring range | ≤30m |
| Ranging accuracy | ≤±1m |
| Repetition frequency | Adjustable from 1Hz to 10Hz |
| Correct Measurement Rate | ≥98% |
| Beam angle | ≤0.5mrad |
| Volume | 48.5×36×26mm |
| Weight | ≤60g |
| Supply voltage | DC+5V |
| Operating temperature | -40℃~+60℃ |
| Storage temperature | -50℃~+70℃ |
Note: All performance specifications and interfaces can be customized to meet specific requirements.
Certifications
Compliant with CE, FCC, and RoHS standards (customizable per regional requirements).
